• Dual Roll Split Shaft for Pro 32r+ consists of two individual motorized airshafts.
• Ensure precise and accurate media collection and improved media advance, resulting in excellent print quality.
• Enable printing simultaneously on two media rolls with different diameters.
• Tension between the rolls is automatically adjusted according to media diameter.
• Media loading and unloading is flexible, simple and quick
• Shafts can be inflated to fixate the media and avoid its shifting sideways
• Supports media rolls up to 200 kg | 441 lbs /per shaft

blob:https://www.efi.com/0d416fad-00f6-4d73-b297-3572e4b323a1

A set of accessories that facilitate neat media feeding/collecting, holding in place media rolls that are positioned directly on the rear or front printer rolls, preventing them from shifting sideways.

• Delivered with EFI roll-to-roll printers (excluding the EFI Pro 32r+), the standard kit for single-roll media collecting includes:
  • One pair of back media limiters
  • One pair of front media limiters
  • One pair of media disks for attaching to both ends of 3 in core (can be used for both front and back)
• Additional multi-roll media collection kits (front) can be ordered separately (one for 118.11 in (3 m), two for 196.85 in (5m))

A pair of clamp-like devices that stretch the media sideways to enable neat media inlet to the printer.

• Helps prevent potential media wrinkles
• Improves media advance
• Facilitates printing on various types of challenging media
• Easy to install at both ends of the press beam on the rear of the printer
• Position and tilt angle are adaptable to the media type and width
• Two units are included as standard with the VUTEk 5r+

Fully integrated unwinder or rewinder option for the EFI roll-to-roll printers.

• Enables working with heavy 3 m media rolls up to 1,750 lbs (793 kg)
• Enables continuous, uninterrupted work without stopping to change rolls
• Increases productivity in high volume runs due to less make-ready
• Equipped with dancer and external motor
• Material width: 126 in (320 cm)
• Maximum media diameter: 27.5 in (70 cm)
• Standard 3 in core; optional 6 in core

• Max weight refers to 126 in (3.2 m) full-width rolls only
• For information on narrower roll widths, please contact customer service

• Optional Media Edge Guards are used for specialty media types with uneven or wavy edges, that tend to curl or unravel, such as textiles and wallpaper.
• Designed to protect the print carriage and printheads from crashing into the uneven media edges.
• Eliminate ruined jobs and prevent wasted media
• Can be attached quickly and easily with magnets, anywhere along the printing table.
• Use as many units as needed. Use multiple units for multi-roll printing

Integrated winder and unwinder solution with motorized pneumatic inflatable core shafts for precise and excellent media collection.

• Improves media advance and print quality
• Allows using larger and heavier rolls
• Supports full printer width media as well as multi-roll
  • 2 m x 1.6 m units for 3-meter printer models – front / back
  • 3 m x 1.6 m units for 5-meter printer models – front / back
• Applicable for EFI VUTEk 3r+ & 5r+and the VUTEk D3r & D5r printers

Specifications:

• Basic unit – front / back: 63 in (1.6 m) width / 3 in core
• Max media weight: 882 lbs (400 kg)
• Max media diameter: 19 in (50 cm)
• Additional airshaft cores – front / back:
  •  63 in (1.6 m) width / 6 in core
  • 126 in (3.2 m) width / 3 in core
  • 196.85 in (5 m) width /3 in core
• All flexible media types supported

Automatic patented system for perfectly aligned double-sided backlit printing on backlit media.

• Accuracy of ≤ 2 mm over 10 linear meters
• Camera-guided software automatically corrects registration on the x, y and tilt axes
• Includes two cameras, a LED strip along printing table and dedicated software
• Simple, easy and fully automatic system
• Eliminates the need for guesswork and manual manipulation
• Reduces required operator skill level

Notes:

• Minimum image width: 16.54 in (42 cm)
• Automatic backlit is not compatible with multi-roll printing
• Use of X-cutter and Y-slitters with automatic backlit is limited
  • Slitter is not supported
  • Cutter is available on B side, according to built-in instructions

An automatic system which enables printing on both sides of opaque blockout media, resulting in excellent registration between sides.

• Accuracy of ≤ 5 mm over 10 linear meters
• Includes an optical sensor system, dedicated electronics and software
• Simple, easy and fully automatic system
• Eliminates the need for guesswork and manual manipulation
• Reduces required operator skill level
• Two available workflows, to be defined before printing:
  • Head-to-head printing for short jobs where media is rolled back, flipped over and reinstalled with side B up
  • Head-to-tail printing for longer jobs where printed media is collected on a front core, flipped over and reinstalled with side B up

Notes:

• Automatic blockout supports multi-roll printing on side A, and single-roll printing for side B
• Use of X-cutter and Y-slitters with automatic blockout is partial
  • Slitters can be used according to built-in instructions
  • Cutter can be used for side B

• Enables seven-color printing, by adding three light colors
  • Light cyan, light magenta and light black
• Based on existing print-head configuration, without adding more heads
• • Expanded color gamut
  • Smooth gradient transitions
  • Vivid and crisp colors
  • Fine details
  • Smooth skin tonesBenefits:

Note: Seven-color printing is supported on VUTEk 3r+ & VUTEk 5r+

• Printed inline, simultaneously with the image without slowing production speed
• Enhances the output, adding extra pop to the colours, offering beautiful creative possibilities
• Full flood or selective
• Glossy or matte finish with the same ink
• Provides three years of outdoor protection against
  • Abrasion and scratching
  • Chemicals such as detergents, gasoline, and IPA
  • Weather damage
  • Air pollution
  • UV fading/yellowing
• Saves time versus separate offline coating systems

• Enables printing on coloured and transparent media
• Opens up a myriad of creative possibilities
• Instant uptime of white printheads thanks to advanced circulation system in the ink tanks and along entire ink system
• Multiple white print modes for various challenging applications:
  • White only
  • White as background
  • White on top of color
  • Three-layer printing for backlit applications (c-w-c)
  • Five-layer printing (c-w-k-w-c) for blockout printing on clear media
  • Various additional thee- and five-layer print modes

Automated device which takes printed cut sheets directly from the printer, rolls them into scrolls, and tapes their edges with labels which have job information printed on them.

• Synchronized with the inline finishing workflow
• Delivers labelled printed rolls immediately following printing

Specifications:

• Maximum media width: 63 in (1.6 m)
• Minimum media width: 15.7 in (40 cm)
• Maximum total linear media length (single sheet or multiple copies rolled together): 13.12 ft (4 m)
• Maximum roll diameter: 2.3 in (6 cm)
• Productivity: Supports all print modes (from 1 pass up)
• Media type support: A wide range of flexible display graphics media, such as vinyl, paper and PVC banner
• Multi-roll printing: Supports 63 in (1.6 m) rolls; two units for 3-meter printer models, three units for 5-meter printer models

A printing device that prints file information on the rear of the media, facilitating the identification of the finished job for packing, shipping, and installation.

• Printed data includes: File ID, printing date and time, print mode, copy number, and more
• Saves time during installation of printed job
• Eliminates the need for manual labelling
• Helps prevent shipping errors
• Saves time during installation of printed job

Specifications:

• Does not support barcodes or QR codes
• Applicable to jobs of 36 in (100 cm) in linear length and longer

For vertical trimming of margins or slitting of a single media into multiple jobs.

• Cuts media on the Y-axis on-the-fly, simultaneously with printing
• Modifiable configuration:
  • Single-bladed for trimming margins
  • Double-bladed for slitting of single media into two jobs (blades are fixed 8mm apart)
• Simple and easy installation with no tools required
• Easy manual adjustment of position along printing table
• Retractable blades for maximum safety
• Minimize media waste and increase the printing area
• Waste collectors roll up the trimmed remnants. Increase your overall productivity and say goodbye to the mess.

Unique roll-to-sheet horizontal cutter incorporated in the printer.

• Automatically cuts media on the X axis between jobs, on-the-fly
• Controlled via the front-end software
• Does not affect productivity
• Saves valuable time at finishing station
• Replaces expensive cutting equipment and saves space
•  Prevents finishing errors and increases yield

Specifications:

• Maximum cutting width in 5 m printers: 197 in (500 cm)
• Maximum cutting width in 3 m printers: 118 in (320 cm)
